Specifications
Engine
- Engine Model
- Cat C9.3B
- Power - Net
- 215hp
- Net Power - Rated - ISO 9249/SAE J1349
- 215hp
- Net Power (Rated) - ISO 9249 (DIN)
- 219mhp
- Emissions
- U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V
- Note (1)
- Rated horsepower at 2,200 rpm. Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions module and alternator. Advertised power is tested per the specified standard in effect a
- Note (2)
- Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 20% biodiesel FAME (fatty acid methyl ester) ** or 100% renewable diesel, HVO (
- Note (3)
- Basic machine specs provided below. For complete specifications and dimensions by configuration, blade and track shoe offerings and more, please visit the product download section to view the full Technical Specifications document.
- Note (4)
- Machine Build Number 20B
Weights
- Operating Weight
- 50733lb
Transmission
- Powertrain
- Fully Automatic 4-Speed Powershift
Service Refill Capacities
- Fuel Tank
- 90gal (US)
- DEF Tank
- 7.4gal (US)
D6 Push Arm
- Operating Weight
- 48788lb
- Ground Pressure
- 7.9psi
- Width of Standard Shoe
- 24in
- Blade
- Semi-Universal (SU)
- Blade Capacity
- 7.5yd³
D6 LGP (30-in) Push Arm
- Operating Weight
- 50420lb
- Ground Pressure
- 6.5psi
- Width of Standard Shoe
- 30in
- Blade
- Semi-Universal (SU)
- Blade Capacity
- 7.6yd³
D6 LGP (36-in) Push Arm
- Operating Weight
- 52715lb
- Ground Pressure
- 5.2psi
- Width of Standard Shoe
- 36in
- Blade
- Straight
- Blade Capacity
- 5yd³
D6 VPAT
- Operating Weight
- 49108lb
- Ground Pressure
- 7.1psi
- Width of Standard Shoe
- 24in
- Blade
- VPAT
- Blade Capacity
- 5.4yd³
D6 LGP (30-in) VPAT
- Operating Weight
- 50733lb
- Ground Pressure
- 5.9psi
- Width of Standard Shoe
- 30in
- Blade
- VPAT
- Blade Capacity
- 5.9yd³
D6 LGP (36-in) VPAT
- Operating Weight
- 51912lb
- Ground Pressure
- 5psi
- Width of Standard Shoe
- 36in
- Blade
- VPAT
- Blade Capacity
- 6.5yd³
Sustainability
- Recyclability
- 98%
Air Conditioning System
- Air Conditioning
- The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.36 kg of refrigerant which has a CO2 equivalent of 1.946 metric tonnes.
