Specifications
Dimensions
- Machine Class
- 6 Ton Mini Excavators
- Weight
- 463lb
- Interface Options: Top-Bottom
- S-40 / S-40
- Overall Height
- 32.2in
- Length
- 20.7in
- Overall Width
- 19.3in
- Rotation Speed
- 7 Seconds per 1 Full Rotation
- Tilt Angle Range +/-
- 40 degrees left/right
- Maximum Bucket Capacity
- 8.8ft³
- Maximum Bucket Width
- 47.2in
- Optimal Hydraulic Flow
- 45-80 L/min (12-21 gpm)
- Maximum Operating Pressure
- 3625.9psi
- Required Hydraulics
- 1st Auxiliary
- Tilting Torque
- 10627lb/ft
- Turning Torque
- 2876.5lb/ft
