Specifications
Cutting System
- Milling Width
- 98.6in
- Maximum Milling Depth
- 13in
- Rotor Speeds
- 100 / 109 / 118 rpm
- Number of Bits
- 203
Power Train
- Rated Power
- 806hp
- Engine
- Cat C18 twin-turbo
- Maximum Travel Speed
- 3.7mile/h
- Maximum Milling Speed
- 328ft/min
Weights
- Operating Weight
- 82673lb
- Transport Weight
- 74075lb
Dimensions
- Operating Length - Conveyor Up
- 47.64ft
- Operating Width
- 11.02ft
- Height - Canopy
- 13.29ft
- Maximum Truck Clearance
- 15.94ft
- Minimum Right Cutting Radius
- 4.92ft
- Minimum Left Cutting Radius
- 6.56ft
- Conveyor Swing
- 60 degrees from center
- Transport Length
- 40.78ft
- Transport Width
- 9.88ft
- Transport Height
- 9.84ft
Service Refill Capacities
- Water Spray System Tank
- 898.2gal (US)
- Cooling System
- 27.5gal (US)
- Fuel Tank
- 292.7gal (US)
- Engine Oil
- 17.2gal (US)
- Hydraulic Tank
- 29.9gal (US)
