Specifications
Engine
- Flywheel Power
- 202hp
- Engine Model
- Cat C7.1
- Net Power - ISO 9249/SAE J1349
- 202hp
- Net Power - ISO 9249 (DIN)
- 204mhp
- Emissions
- Meets U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, China Nonroad Stage IV, Japan 2014 emission standards or India Bharat Stage III, Eurasian Economic Union Stage IIIA, UN ECE R96 Stage IIIA emission standards, equivalent to U.S. EPA Tier 3/ EU Stage
- Note (1)
- Cat U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, China Nonroad Stage IV, Japan 2014 engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: 2
- Note (2)
- Net power advertised is the power available at the engine flywheel when the engine is equipped with a fan, air cleaner, clean emissions Module (when equipped) and alternator. Advertised power is tested per the specified standard in effect at the time of m
Weights
- Operating Weight
- 44881lb
Buckets
- Capacity - General Purpose
- 3.2yd³
- Capacity - Multi-Purpose
- 2.6yd³
- Capacity - Performance Series
- 3.7yd³
- Width - General Purpose
- 101.2in
- Width - Multi-Purpose
- 101.3in
- Width - Performance Series
- 105.2in
Service Refill Capacities
- Fuel Tank
- 84.5gal (US)
- DEF Tank
- 4.2gal (US)
Standard
- Operating Weight
- 44881lb
- Width of Standard Shoe
- 22in
- Ground Contact Area
- 4900in²
- Ground Pressure
- 9.1psi
Low Ground Pressure (LGP)
- Operating Weight
- 50181lb
- Width of Standard Shoe
- 31in
- Ground Contact Area
- 7136in²
- Ground Pressure
- 7psi
Waste Handler
- Operating Weight
- 45549lb
- Width of Standard Shoe
- 22in
- Ground Contact Area
- 4900in²
- Ground Pressure
- 9.2psi
Dimensions
- Overall Machine Length*
- 275.6in
- Machine Height - Top of Cab
- 130.9in
- Height - Top of Stack
- 115.7in
- Overall Machine Height - Bucket Fully Raised
- 212.7in
- Overall Machine Width without Bucket: With Standard Tracks - 550 mm (21.6 in) Shoes
- 94.5in
- Note
- *With General Purpose bucket and extra duty teeth.
Undercarriage
- Track Gauge
- 72.8in
- Track on Ground
- 100in
- Track Rollers/Shoes - Each Side
- 7 / 38
Air Conditioning System
- Air Conditioning
- The air conditioning system on this machine contains the fluorinated greenhouse gas refrigerant R134a (Global Warming Potential = 1430). The system contains 1.1 kg of refrigerant which has a CO2 equivalent of 1.573 metric tonnes.
